Disconnect tone FXO

VoIP шлюз с FXO портом должен понимать,
что абонент ТФОП повесил трубку.

Disconnect tone:

X@-30,X@-30;Y(A/B/1+2)

Примеры для некоторых шлюзов

Basic setup > Tone

425@-30,425@-30;4(.34/.34/1+2)

Cisco SPA Disconnect Tone examples

The Disconnect Tone Script values for various countries follow:

US—480@-30,620@-30;4(.25/.25/1+2)

UK—400@-30,400@-30; 2(3/0/1+2)

France—440@-30,440@-30; 2(0.5/0.5/1+2)

Germany—425@-10; 10(0.48/0.48/1)

Netherlands—425@-30,425@-30; 2(0.5/0.5/1+2)

Sweden—425@-10; 10(0.25/0.25/1)

Norway—425@-10; 10(0.5/0.5/1)

Italy—425@-30,425@-30; 2(0.2/0.2/1+2)

Spain—425@-10; 10(0.2/0.2/1,0.2/0.2/1,0.2/0.6/1)

Portugal—425@-10; 10(0.5/0.5/1)

Poland—425@-10; 10(0.5/0.5/1)

Denmark—425@-10; 10(0.25/0.25/1)

New Zealand—400@-15; 10(0.25/0.25/1)

Australia—425@-13; 10(0.375/0.375/1)

Tones

voice class clear-down-tone
0 425 0 340 340

или

0 425 0 300 300
